| Dimensions (W x D x H) (with chassis ears) |
mm : 483 x 679 x 173.5
inches : 19 x 26.7 x 6.8 |
| Industry Standard |
| EIA-RS310D |
| Material |
| Heavy-duty preplated SPGC cold-rolled steel |
| Color |
| Front Panel : Black |
| Cooling |
| Middle : 6 x 80x38mm PWM & low-power consumption hot swap fans |
| Power Supply |
| 1200W 1+1 redundant PSU PMBus 1.2 80+ Platinum |
| Expansion Slots |
| 7 low profle |
| Front Panel |
Power on/off
System reset
2 x USB 3.0 port |
| LED Indicators |
Power
LAN
Drive
Alert |
| System Board |
| 12”(W) x 13”(D) E-ATX/SSI EEB 3.6 compliant MB |
| Drive Bays |
External : 36 x 3.5” hot swap
Internal : 2 x 2.5” |
| Backplane |
1 x 24-port 12Gb SAS backplane with 36-PHY expander and 3 SFF-8643 connectors
1 x 12-port 12Gb SAS backplane with 28-PHY expander and 3 SFF-8643 connectors |
| Storage Temperature |
| 0°C(32°F) ~ 50°C(122°F) |
| Humidity |
| 5% ~ 95% non-condensing |
| Gross Weight (w/ PSU & Rail) |
kgs : 40.4
lbs : 89 |
| Package Dimension (W x D x H) |
mm : 616 x 921 x 393
inches : 24.3 x 36.3 x 15.5 |
| Cubic Feet |
| 7.6 |
| Container Load Quantity |
20’ : 110
40’ : 230
40’ H : 295 |
| Mounting |
| Standard : 26” tool-less slide rail |
